Product Details:
|
| Capacity: | 51.2V 105Ah | Nominal Voltage Voltage: | 51.2V |
|---|---|---|---|
| Rated Capacity: | 105Ah | Energy: | 5376Wh |
| Application: | ESS, Solar System | Cycle Span: | 3000-5000 Cycles |
| Compact Desiged: | With Built-in BMS | Self-diacharge Rate: | <3% |
| Communication: | CAN, RS232, RS485 | OEM/ODM: | Available |
| High Light: | 51.2V Rechargeable Lithium Ion Battery,105Ah Rechargeable Lithium Ion Battery,Golf Cart 48V LiFePO4 Battery |
||
Golf Cart Battery Advantages
This 51.2V 105Ah LiFePO4 battery can be suitable for the golf cart, EV ,sccoter... ...
We also provides customized batteries with different capacity, dimension and functions according to customer's specific requirements.
1. Communication Function.
Support RS485/CAN and also optional for bluetooth and LCD display for checking the battery status well.
2. Built-in BMS
3. Long Cycle Life
LiFePO4 battery has a longer life cycle which is more than 5000 times and its life span is up to 10 years.
4. Wide Working Temperature
Li-ion battery has wide working temperature range of -20°C ~ 60°C.
5. Environmental Friendly
Lithium battery is safety and do not have any harmful heavy metal elements, it is green, non-toxic, pollution-free.
| Electrical Characteristics | Nominal Voltage | 51.2V |
| Nominal Capacity | 105Ah | |
| Energy | 5376Wh | |
| Internal Resistance | ≤10mΩ | |
| Cycle Life | >6000 cycles@1C 100% DOD | |
| Months Self Discharge | <3% | |
| Efficiency of Charge | 100%@0.5C | |
| Efficiency of Discharge | 96-99% @1C | |
| Standard Charge | Charge Cut-off Voltage | 58.4±0.2V |
| Charge Mode | 0.2C to 58.4V, then 58.4V charge current to 0.02C(CC/CV) | |
| Recommend Charge Current | 55A | |
| Max. Charge Current | 100A | |
| Standard Discharge | Max. Continuous Discharge Current | 200A |
| Max. Pulse Current | 400A(35S) | |
| Discharge Cut-off Voltage | 40V | |
| Environmental | Charge Temperature | 0ºC to 45ºC(32F to 113F)@60±25% Relative Humidity |
| Discharge Temperature | -20ºC to 60ºC(-4F to 140F)@60±25% Relative Humidity | |
| Storage Temperature | 0ºC to 40ºC(32F to 104F)@60±25% Relative Humidity | |
| Water Dust Resistance | IP67 | |
| Mechanical | Cell&Method | 16S |
| Package | Metal case | |
| Dimensions(in./mm.) | 509*334*230mm | |
| Weight(lbs./kg.) | 45kg | |
| Terminal | M8 | |
| Display screen | Optional | |
| Bluetooth | Optional |
Services
1. All of your inquires and emails will be replied within 12 hours
2. Our professional engineer team can provide you one stop battery solution
3. Battery voltage,capacity,case material,BMS and dimension can be customized
4. All of our LiFePO4 battery will be tested one by one before shipment
5. We can print your own logo on case or make customized label
6. We offer 3-5 years warranty and continuous technical support
7. EXW/CIF/DDP trade term are optional. We could arrange the shipmnet for you.
Q1. Can you explain in detail how you match cells for a battery pack before you assembling the pack?
We will do the following things before assembling the pack:
a. Select capacity, same capacities cells for one pack
b. Measure the voltage, same voltage cells for one pack(difference is under 0.02v per cell)
c. Measure the inner resistance,same IR cells for one pack (difference is under 1m Ohm)
All above steps are very strict to make sure the pack performance is perfect.
Q2. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q3: What kind of certificates could you provide for these batteries?
A: We have CE,MSDS,UN38.3 for most our current model, if It's custom-making design, usually no current certificates, we could apply for you if you need, but the related fees should be paid by your side, and if your order is big enough, certificate fees can be refunded.
Q4:Do you have MOQ ?
A:No limited. Small order for quality testing also welcome. The quotation is based on the quantity.
Q5: Can your factory print our logo/brand on the product?
A: Yes, and we will do this free of charge if the order quantity is big enough, please contact us for more details.
Q6. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
