Product Details:
|
| Capacity: | 51.2V 105Ah | Nominal Voltage Voltage: | 51.2V |
|---|---|---|---|
| Rated Capacity: | 105Ah | Energy: | 5376Wh |
| Application: | ESS, Solar System | Cycle Span: | 3000-5000 Cycles |
| Compact Desiged: | With Built-in BMS | Self-diacharge Rate: | <3% |
| Communication: | CAN, RS232, RS485 | OEM/ODM: | Available |
| High Light: | Scooter 48V LiFePO4 Battery Pack,48V LiFePO4 Battery,EV 48V LiFePO4 Battery |
||
Golf Cat LFP Battery Advantage
1.SHORT AND QUICK RELOADING
Battery can be recharged even during short breaks, meaning costly and time-consuming battery changes are no longer necessary.
2.HIGHER ENERGY EFFICIENCY
Up to 30 percent more energy thanks to higher energy density and high overall system efficiency.
3.POWERFUL SYSTEM
No loss of performance even with decreasing battery charge.
4.USER-FRIENDLY SOLUTION
No leaking of hazardous battery gases and acids. Maintenance-free and easy to clean.
| Electrical Characteristics | Nominal Voltage | 51.2V |
| Nominal Capacity | 105Ah | |
| Energy | 5376Wh | |
| Internal Resistance | ≤10mΩ | |
| Cycle Life | >6000 cycles@1C 100% DOD | |
| Months Self Discharge | <3% | |
| Efficiency of Charge | 100%@0.5C | |
| Efficiency of Discharge | 96-99% @1C | |
| Standard Charge | Charge Cut-off Voltage | 58.4±0.2V |
| Charge Mode | 0.2C to 58.4V, then 58.4V charge current to 0.02C(CC/CV) | |
| Recommend Charge Current | 55A | |
| Max. Charge Current | 100A | |
| Standard Discharge | Max. Continuous Discharge Current | 200A |
| Max. Pulse Current | 400A(35S) | |
| Discharge Cut-off Voltage | 40V | |
| Environmental | Charge Temperature | 0ºC to 45ºC(32F to 113F)@60±25% Relative Humidity |
| Discharge Temperature | -20ºC to 60ºC(-4F to 140F)@60±25% Relative Humidity | |
| Storage Temperature | 0ºC to 40ºC(32F to 104F)@60±25% Relative Humidity | |
| Water Dust Resistance | IP67 | |
| Mechanical | Cell&Method | 16S |
| Package | Metal case | |
| Dimensions(in./mm.) | 509*334*230mm | |
| Weight(lbs./kg.) | 45kg | |
| Terminal | M8 | |
| Display screen | Optional | |
| Bluetooth | Optional |
Packaging & Shipping
With high quality pearl wool, UN cartons / Plywood, plastic pallet.
Standard batteries lead time: Samples: 15-20 days, Bulk order: 25-30 days.
Customized batteries lead time: Samples: 30-40 days, Bulk order: 30-40 days.
Shipment:By air, by sea, by express, by railway, etc.
Q: Are you manufacturer or simply trading company?
We are manufacturer, and we sincerely welcome you to visit our factory!
Q: Is it possible to do OEM customizef of battery and packaging with our logo ?.
Yes,OEM/customizing is available , please feel free to contact me with your requirements.
Q: Can we have a sample order?
Yes, we welcome sample order to test the quality, welcome for inquiry.
Q:Where can I get the price?
We will quote the price within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we will regard your inquiry priority.
Q:What shipping ways can I choose and how long?
By Express (3-15 days): suitable for urgent time or small quantity;Q:How do I track my shipment?
After we deliver your goods, we will send you the tracking NO. once your goods has been shipped.
