Home ProductsLiFePO4 Battery Cell

Pouch Lithium Phosphate Packing 3.2V 30Ah Lifepo4 Cylindrical Cells

Certification
China Shenzhen Elite New Energy Co., Ltd. certification
China Shenzhen Elite New Energy Co., Ltd. certification
Customer Reviews
Elite is specializing in producing deep cycle lifepo4 battery and providing professional battery solution according customers' requirements.

—— Igor Booklan

Professional LiFePO4 battery manufacturer for lead acid battery replacement, electric low speed vehicles and energy storage systems.

—— Linda.M

Nice cooperation experience with Elite, they provide high quality batteries and perfect services

—— Georage

I'm Online Chat Now

Pouch Lithium Phosphate Packing 3.2V 30Ah Lifepo4 Cylindrical Cells

Pouch Lithium Phosphate Packing 3.2V 30Ah Lifepo4 Cylindrical Cells
Pouch Lithium Phosphate Packing 3.2V 30Ah Lifepo4 Cylindrical Cells Pouch Lithium Phosphate Packing 3.2V 30Ah Lifepo4 Cylindrical Cells

Large Image :  Pouch Lithium Phosphate Packing 3.2V 30Ah Lifepo4 Cylindrical Cells

Product Details:
Place of Origin: Guangdong, China
Brand Name: Elite Battery
Certification: CE, UL, BIS, MSDS, UN38.3
Model Number: 3.2V 30Ah
Payment & Shipping Terms:
Minimum Order Quantity: 100 PCS
Price: $0.99-$19.99/PCS
Packaging Details: Carton box with pallet
Delivery Time: 30 Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram,Paypal
Supply Ability: 500000 PCS/Month

Pouch Lithium Phosphate Packing 3.2V 30Ah Lifepo4 Cylindrical Cells

Description
Cell Type: 3.2V 30Ah Pouch Cell Rated Capacity: 30Ah
Nominal Voltage: 3.2V Energy: 0.096Kwh
Application: ESS, EV, Solar System Cycle Life: 3000-5000 Cycles
Self-diacharge Rate: <3% Housing: PVC
High Light:

30Ah Lifepo4 Cylindrical Cells

,

Pouch Lifepo4 Cylindrical Cells

,

Cylindrical Lifepo4 Pouch Cells

Pouch Lithium Phosphate Packing 3.2V 30Ah Lifepo4 Cylindrical Cells



Packing 3.2V 30Ah Pouch/Prismatic/Cylindrical LiFePO4 Battery Cell



Product Description



Feature

Lithium iron phosphate battery is with high energy density. The energy density of lifepo4 battery can reached 460-600 Wh/kg at present, about 6-7 times higher than lead acid battery.  Also,  lithium iron phosphate battery has the advantages of non-toxic material contained, non-polluting, excellent safety performance, wide source of raw materials, comparative price and long life span, which is an ideal greener energy to replace lead-acid battery. Besides, lithium iron phosphate battery can be fast charging/discharging: lithium iron phosphate battery can be high current 2C fast charged and discharged, under the special charger ,1.5C charge can make the battery full of capacity within 40 minutes, the starting current can reach 2 C, and the lead acid battery does not have this performance at present.



Nominal Voltage

3.2V

Nominal Capacity

30Ah

Energy

96Wh

Internal Resistance

≤10mΩ

Cycle Life

>3000 cycles@1C 100% DOD

Months Self Discharge

<3%

Efficiency of Charge

100%@0.5C

Efficiency of Discharge

96-99% @1C

Charge Cut-off Voltage

3.65±0.2V

Charge Mode

0.2C to 3.65V, then 3.65V charge current to 0.02C(CC/CV)

Recommend Charge Current

6A

Max. Charge Current

30A

Max. Continuous Discharge Current

30A

Max. Pulse Current

60A(10S)

Discharge Cut-off Voltage

2.5V

Charge Temperature

0ºC to 45ºC(32F to 113F)@60±25% Relative Humidity

Discharge Temperature

-20ºC to 60ºC(-4F to 140F)@60±25% Relative Humidity

Storage Temperature

0ºC to 40ºC(32F to 104F)@60±25% Relative Humidity

Water Dust Resistance

IP54

Cell&Method

1S

Package

PVC

Dimensions(in./mm.)

227*165*10.4mm

Weight(lbs./kg.)

680g



Product Images

Pouch Lithium Phosphate Packing 3.2V 30Ah Lifepo4 Cylindrical Cells 0

Company Information

Introduction

Pouch Lithium Phosphate Packing 3.2V 30Ah Lifepo4 Cylindrical Cells 1

Shenzhen Elite New Energy Co., Ltd is a leading battery manufacturer in China, which is committed to provide customers with safe and durable green energy products, including EV power battery systems, portable energy storage, household energy storage, micro power grid, battery solutions for telecom station power supply, UPS, solar street lights, and battery packs for police car, harvesters, AGV, forklift, balance vehicles, electric tricycles, electric wheelchairs, etc.



Packaging & Shipping



Package: With high quality pearl wool, UN cartons / Plywood, plastic pallet.

Shipping: By air, by sea, by express, railway transportation and so on.



Q&A



1. Where can I get the price?
We will offer you the quotation within 24 hours after receiving your inquiry.
2. What is your MOQ ?
Sample order for testing is available.
3. How can you guarantee your quality.
Elite implements strict quality control in every production process to ensure the stability and consistency of the products. We have a team of professional workers who are engaged in quality management during every process. Besides, all of our products have 3-5 years warranty.
4. What about the lead time of bulk order?
It depends on your order quantity. Elite applies strict production program. Normally, the lead time is 30 days.
5. What shipping method can I choose? How about the shipping time?
By Express (3-15 days): suitable for urgent time or small quantity;
By Sea (25-45 days): suitable for bulk order;
By Railway (15-35 days): Suitable for bulk order.
Our sales person will recommend the most suitable solution for you according to your detailed order and situation.
